Imaging luminance and color measuring devices and products
The imaging analysis of light sources and illuminated scenarios has an increasing demand. The complex analysis of lamps, luminaires and lighting scenarios requires the knowledge about luminances and there spatial distribution for the whole field of view or special areas of interests.
Goniophotometer
Goniophotometer
RiGO801
The near-field goniophotometers of the series RiGO801 measure luminous intensity distributions, ray sets / ray files, luminance distributions and spectral data of LEDs/OLEDs up to large luminaires.
LMK position
LMK position
Vision based robotic
At the present time industrial robots produce a repeatability of 20-30 μm for positioning. Comparing the robotic-controlled LMK with a manually positioned luminance measuring device the former has considerably better reproducibility. The LMK ...

Downloads

Contact
KMP
KMP
compact measuring station
The KMP system allows an indirect measurement of LID (luminous intensity distribution) via an additional optical imaging system. This optical imaging system shortens the photometric limit distance of the light source because the light is projected ...

Downloads

Contact
Image processing station
Image processing station
Digital image processing station
When light emitted by a light source illuminates a reflective wall beyond the photometric limiting distance, the emitted luminous flux causes an illuminance on this reflective wall. This again causes a reflected luminance which can be detected in a ...

Downloads

Contact
Applications
Applications
Tasks and applications of the imaging photometry and colorimetry
Our comprehension of an application means the conception and realisation of an individual technical solution, focussed on one specific task.
